Diameter: 3mm/5mm
Lens Colour : Water Clear
Forward Voltage (V) : 2.2 ~ 3.0
Red:Wave Length:620~630nm ,Luminous:4000~5000lm
Green:Wave Length:520~530nm,Luminous:7000~9000lm
Blue:Wave Length:460~465nm,Luminous:5000~6000lm
Reverse Current (uA) : <=10
Luminous Intensity Typ Iv (mcd) : Average in 2000
Life Rating : 200,000 Hours
Viewing Angle : 20 ~ 25 Degree
Absolute Maximum Ratings (Ta=25°C)
Max Power Dissipation : 80mw
Max Continuous Forward Current : 30mA
Max Peak Forward Current : 20mA
Reverse Voltage : 5~6V
Lead Soldering Temperature : 240°C (<5Sec)
Operating Temperature Range : -25°C ~ +85°C
Preservative Temperature Range : -30°C ~ +100°C ![]()
![]()
![]()
